HELLA VALUEFIT 1GJ 360 003-002 LED-Worklight Lightbar LBX-720 - 12/24V

Item Attributes:
Mounting Type: mounting / Bolted
Fastening Type: Vertical / Suspended
Light Design: LED
Lamp Type: LED
Voltage: 12 V / 24 V
Height: 86 mm
Width: 704 mm
Depth: 80 mm
Light Distribution: Long-range illumination
Fulfils ECE norm.: R10
Plug: DEUTSCH plug
Prot.type (IP Code): IP6K7 / IP6K9K
Luminous Flux: 5500 lm
Colour Temperature: 6500 K
Number of LEDs: 12
Power consumption: 88 W
Cable: 2000 mm
Housing Type: Aluminium Housing
Housing Colour: Black
Diffusing Lens Material: Glass
Diffusing Lens Type: Patterned diffusing lens
Assembly by qualified personnel required!

The new light bar series includes four worklights in an elongated design in different lengths and light intensities. Cooling fins on the back of the aluminium housing ensure the necessary heat dissipation of the high-power LEDs. The innovative lens technology of the LBX Lightbars creates homogeneous illumination for both near-field and far-field illumination. The light intensity starts with the LBX 220 LED at 1000 lumens and extends to the powerful LBX 720 LED with an effective light output of 5500 lumens. For optimal illumination a low mounting height of between 0.50 and 1.50 metres is recommended. This distributes the light over a large area and evenly into the workspace significantly improving working conditions at night. The longer LBX 540 and LBX 720 versions offer the combination of wide-beam lenses for the near-field area and narrow-beam lenses in the centre for long-range illumination. The perfect combination for large-area illumination in front of the vehicle.
